EclProfile FS RGB+Lime , Opt. Optics , Black

EclProfile FS RGB+Lime , Opt. Optics , Black

Name: EclProfile FS RGB+Lime , Opt. Optics , Black
Brand: Prolights

530061752

LED profiler, 91x3W RGBL LED, opt.optics, 4 blades, IP20, 200W, 7,3 kg, black

Description Specification Brand information Downloads

EclProfile FS is a full colour elipsoidal LED, designed to deliver a full range of pastels, saturates and whites, both with or without gobos. The EclProfile FS’ RGB + Lime LED engine has been specially engineered to provide a full spectrum and full output in the most discerning environments, regardless of which role the EclProfile FS is playing.

Technical Specifications

LIGHT SOURCE

Source: 91x3W RGB + lime LEDs
CCT: @full 5.000K
Luminous flux: (5°) TBD; (10°) TBD; (14°) 4'619 lm; (19°) 5'133 lm; (26°) 6'100 lm; (36°) 5'970 lm; (50°) 5'596 lm; (70°) TBDlm @full
Lux: (5°) TBD; (10°) TBD; (14°) 4'321 lx; (19°) 2'567 lx; (26°) 1'711 lx; (36°) 873 lx; (50°) 462 lx; (70°) TBDlx @5 m full
CRI: 86 @3.200 K; 85 @5.600 K
TLCI: 82 @5.600 K
TM30 Rf: 84 @3.200 K
TM30 Rg: 109 @3.200 K
Source life expectancy: > 50.000 h

OPTICS

Lens type: high-quality glass lens optics
Additional optics: optional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50
Focus: manual

COLOUR SYSTEM

Colour mixing: RGB + lime / full colour
CCT: CCT control through dedicated DMX channel
White presets: 2.700 K ~ 10.000K
Colour wheel: virtual colour wheel with macros
Macros: several pre-build pixel macros with adjustable speed

DYNAMIC EFFECTS

Gobo size: B, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Static mode: selection of static colour
Manual mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
Special features: different presets for fan mode and output management

BODY

Body: sturdy die-cast aluminium body
Body colour: black

CONTROL

Protocols: DMX512, RDM
DMX channels: 1 / 2 / 3RGB / 4RGBL / 5RGBL / 3 / 4 / 5 / 8 / 13 ch - Tungsten / 3.200 K / 5.400 K / 6.500 Kchannel
RDM: RDM for remote monitoring and settings
Display: Graphic User Interface
Firmware upgrade: yes, via USB - DMX interface (UPBOX2) not included
Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 25 Hz, electronic
Display battery: self-charging battery backup
Operating temperature: -20° ~ +45°
LED Control: flicker free operation
Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

Mains power supply: 100-240V - 50/60Hz
Max power consumption: 200W
Output (at 230V): 10 units on a single power line
Power factor: > 0,95

PHYSICAL

IP rating: 20
Cooling: low noise fan
Suspension and fixing: bracket for hanging and positioning
Signal connection: Amphenol XLR 5p IN/OUT connectors
Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
Dimensions (WxHxD): 265x259x540mm
Weight: 7,3kg

Supplier SKU

ECLFSBK

Prolights

PROLIGHTS is the professional lighting division of Music & Lights S.r.l., an Italian company specialized in the manufacture of technologies for the show industry.

The PROLIGHTS brand was established in 2001 with a focus on the design and manufacture of professional lighting & video products for the entertainment, event, broadcast and installation markets.

PROLIGHTS is headquartered in Minturno, Italy, where the companies commerical, operational and R&D centres are all located.

PROLIGHTS continues to experience a sustained growth across all sectors, with its products found on stages and in studios all over the world. Founder Franco Sorabella, and his son Fabio, are both actively involved in the day-to-day running of the business and in the development of the product range.

http://www.prolights.it
