ECL DISPLAY RGB+WW CRMX and wired control, w/o lens

CRMX

ECL DISPLAY RGB+WW CRMX and wired control, w/o lens

Name: ECL DISPLAY RGB+WW CRMX and wired control, w/o lens
Brand: Prolights

40W gallery light

Housing Colors

Please select variant!

Description Specification Brand information Downloads

The EclDisplay CRMX series presents an innovative and versatile range of LED spotlights, designed for use in galleries, commercial spaces, and other public venues. These advanced fixtures are distinguished by their refined design and multiple control options, including both wired and wireless protocols. They are adaptable to a variety of applications, thanks to the availability of different sources and optics.

Each EclDisplay CRMX unit can be programmed and controlled via RDM, encompassing a comprehensive array of built-in input control protocols such as Wireless CRMX, DMX and local knob dimming.

At the heart of the EclDisplay CRMX is a highly efficient 40 W RGB+WarmWhite, LED source, capable of delivering both a Full Colour spectrum and also tuneable White. The fixture's versatility is further enhanced by an extensive range of optional accessories, including profile (zoom and static) or wash lenses and additional optical elements like louvres and snoots. This makes the EclDisplay CRMX not just a lighting fixture, but a comprehensive lighting solution adaptable to a multitude of environments and needs.

[5 YEARS WARRANTY]

Main features:

Data control through wireless CRMX, RDM, DMX and local knob dimming
40W RGB+WarmWhite LED
Multiple lens options: Profile (zoom and static) or wash optics

Technical Specifications

LIGHT SOURCE

Source: 40W RGB + Warm White LED
Luminous flux: (profile 2040 - min) 388 lm - (profile 2040 - max) 344 lm; (wash 2550 - min) 357 lm - (wash 2550 - max) 466 lm; (wash 1530 - min) 363 lm - (wash 1530 - max) 402 @full
Lux: (profile 2040 - min) 194 lx - (profile 2040 max) 44 lx; (wash 2550 - min) 57 lx - (wash 2550 - max) 23 lx; (wash 1530 - min) 143 lx - (wash 1530 - max) 68lx @5 m full
Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

Zoom: (wash lens - optional) 15° ~ 30° or 25° ~ 50° - (profile lens - optional) 10° ~ 20° or 20° ~ 40° or 8°
Other: 360° lens rotation - shutter blades lockable - optional 360° rotating barndoors and gel frame holder
Other: (profile lens) shutter blades lockable
Other: (profile lens - optional) manual rotating gobo holder size E, outer: 37 mm - image: 23 mm - thickness: max 3 mm

COLOUR SYSTEM

Colour mixing: RGB + Warm White
CCT: CCT control through dedicated DMX channel
Colour wheel: virtual colour wheel with macros

DYNAMIC EFFECTS

Control Resolution: 16-bit dimmer, colours
Static mode: selection of static colour
Manual mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment

BODY

Hardware on-board: lockable tilt with screw
Body: aluminium die-casting
Body colour: RAL 9004 or RAL 9010
Other: cable not included - Cable diameter range: 6 - 10 mm

CONTROL

Protocols: Local Knob, DMX, RDM, CRMX
Stand Alone: 1 push encoder
DMX channels: 5 / 6 / 15channel
Wireless Control: included, LumenRadio TiMo receiver
RDM: RDM for remote monitoring and settings
Display: user interface through DATAMASTER external coder (not included)
Firmware upgrade: yes, via USB - DMX interface (UPBOXPRO/UPBOX1) not included

ELECTRONICS

Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 selectable dimming modes available
Strobe / shutter: 1 - 30 Hz, electronic
LED Control: flicker free operation
Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

Mains power supply: 100-240V - 50/60Hz
Max power consumption: 35W
Output (at 230V): 40 units on a single power line
Power factor: > 0,94
Inrush current: 110VAC/5.5A, 230VAC/13.75A

PHYSICAL

Operating Temperature: -10° ~ +45°
IP rating: 20
Cooling: passive cooling and fan-free
Suspension and fixing: track / hanging / ceiling installation
Data connection: screw terminal blocks
Power connection: screw terminal blocks
Dimensions (WxHxD): 141X200x150mm / 5.55''x5.91''
Weight: 1,4kg / 3.09lbs

CERTIFICATIONS / APPROVALS

Certifications / Approvals: CE, RCM

Supplier SKU

ECLDISPLAYCRMXFCB

Control sticker

CRMX

IP Rating

IP20
